起源の場所:
中国本土
ブランド名:
FMS
証明:
ISO CE
モデル番号:
二重層
ビデオ
ビデオ
| Part details | Item Name | Specification |
|---|---|---|
| Manual uncoiler | carrying capacity | tons |
| Stype | Manual | |
| Raw coil | Coil material | steel |
| Coil thickness | 0.3-0.8 mm | |
| Machine body | Roller station | 15 station |
| Roller material | 45# steel | |
| Shaft material | 45# steel | |
| Shaft diameter | 75 mm | |
| Machine weight | About 8.5 tons | |
| Machine size | 5-7.5*1.3*1.3 m | |
| Speed | 8-15 m/min | |
| Cutter | Operate | Hydraulic cutting |
| Blade material | Cr12 | |
| Power | Operate | Chain transmission |
| Chain size | 1 inch chain | |
| Control system | PLC brand | Taiwan delta |
| Motor power | 7.5 kw | |
| Hydraulic pump power | 4 kw | |
| Voltage | 380V 50Hz 3phase | |
| Machine color | As ur need | |
| Machine language | Chinese and English |
問い合わせを直接私たちに送ってください.
